2-port Etherent to 232/485 Serial Server
Product Details
Product Advantage
Product Parameter :
| The GP-C4002 Wireless Serial Port Server oroduct features a high-per formance 32-bit profess ional network communication processor, With the embedded real-time operating system as the software support platform, security for the users, high speed, Stable and reliable 2.4G wireless to etheric turn serial port network interface supports 1 Ethernet RJ45 interface and 1-way 2. 4GWIFI and 2- -way communication serial port. Wireless supports the IEEE802. 11b/g/n standard protocol, The system has a built-in TCP / UDP protocol to conduct data conversion and transmission, Multiple VPN protocols are built in the module system to secure data transmission. |
Hardware function | |
| CPU | High-performance Qualcomm processing chip |
| Flash | 128Mb |
| RAM | 1024Mb |
| WIFI | Support for IEEE802.11b/g/n standards |
| Encryption method | Support WEP, WPA, WPA2,etc |
| Theoretical broadband | 150M |
| Transmitting power | 16-17dBm(11g), 18-20dBm(11b) 15dBm (11n ) |
| Acceptance sensitivity | <-72dBm@54Mpbs |
| Software function | |
| WIFI | AP mode, client mode |
| Ethereum | Static IP / dynamic IP |
| Gorge line | Support for TCPserve / TCPclient support UDP Modbus protocol |
| VPN | Various protocols such as PPTP, L2TP, and IPSec |
| Device mangement | local configuration |
| Interface and power supply | |
| Gorge line | RS-232, RS485 |
| LAN | One LAN port, adaptive MDI / MDIX, with built-in isolation protection |
| Electromagnetic pilot lamp | one 1 X PWR, one 1 X Ethernet, one 1 X WiFi, a one 2X COM indicator light |
| Antenna interface | 1 standard SMA antenna interface |
| Peset on | Press this key for 10 seconds to restore the device configuration to factory values |
| Power supply | DC power supply |
| Supply voltage | DC 7.5V ~ DC 32V (standard DC 12V / 1.5A), built-in power supply Instantly Pressure protection |
| Environmental and physical performance | |
| Storage temperature | -45 ~ 85ºC |
| Humidity | 5%~ 95%No condensation |
| External dimension (excluding bracket) | 97mm 67mm 25mm (long, width and height) |
| Installation and fixation | CInstall the ears on the side of the structure |
| Special design | IP34 protection level, electromagnetic shielding, windproof, sun protection, shock prevention, and heat dissipation design |
| Product choosing type | |
| GP-C4002 | Wireless wifi serial port server |
