8+2 Gigabit Unmanaged POE Switch
Product Details
Product Advantage
Product Parameter :
Hardware Specifications | |
Model | GP-1010G-G (150W) |
Ports | 8*10/100/1000 POE 2*10/100/1000 uplink |
Feature | 8*10/100/1000M PoE ports 2*10/100/1000M RJ45 uplink ports Port 1-8 can support IEEE802.3af/at PoE standard. Built-in 150W power supply. |
Interface Characteristics | |
Fixed Port | 4*10/100/1000Base-T PoE ports (Data/Power) 2*10/100/1000Base-T uplink RJ45 ports (Data) |
Ethernet Port | Port 1-6/ Port 1-10 support 10/100/1000Base-T auto-sensing, full/half duplex MDI/MDI-X self-adaption |
Twisted Pair Transmission | 10BASE-T: Cat3, 4, 5 UTP(≤100 meters) 100BASE-TX: Cat5 or later UTP(≤100 meters) 1000BASE-T: Cat5e or later UTP(≤100 meters) |
SFP Slot Port | - |
Optical Cable/ Distance | Multi-mode: 850nm/ 0-500M, Single-mode:1310nm/0-40KM, 1550nm/ 0 -120KM. |
Chip Parameter | |
Network Protocol | IEEE802.3 10BASE-T, IEEE802.3i 10Base-T IEEE802.3u 100Base-TX, IEEE802.3ab 1000Base-T, IEEE802.3x |
LED Indicator | Power: PWR (Green), Network: Link (Green), PoE: PoE (Green) |
Forwarding Mode | Store and Forward(Full Wire Speed) |
Switching Capacity | 16Gbps (Non-blocking) |
Forwarding | 9.2K |
MAC | 8K |
Buffer Memory | 2M |
Jumbo Frame | 8.93Mpps |
PoE & Power Supply | |
PoE Port | Port 1 to 4 |
Power Supply Pin | 1/2(+) 3/6(-) |
Max Power Per Port | 30W, IEEE802.3af/at |
Total PWR / Input Voltage | 150W/ (AC100-240V) |
Power Consumption | Standby<6W, Full load<140W |
Power Supply | Built-in power supply, AC100~240V 50-60Hz 1.1A |
Physical Parameter | |
Operation TEMP / Humidity | -20~+55°C, 5%~90% RH Non condensing |
Storage TEMP / Humidity | -40~+75°C, 5%~95% RH Non condensing |
Dimension (L*W*H) | 140*115*40mm |
Net /Gross Weight | 1.2/1.5kg |
Installation | Desktop, Wall-mounted |
Certification & Warranty | |
Lightning Protection | Lightning protection: 4KV 8/20us, Protection level: IP30 |
Certification | CCC, CE mark, commercial, CE/LVD EN62368-1, FCC Part 15 Class B, RoHS |
Warranty | 1 year, lifelong maintenance. |
