Introduction
GP-R520 series is an industrial-grade 4G WiFi router with high-adaptability, high-reliability and high-stability. It supports FDD-LTE,TDD-LTE,WCDMA(HSPA+), CDMA2000(EVDO), TD-Scdma 3G/4G mobile network. GP-R550 series provid 1*Gigabit LAN ports, 1*Gigabit WAN port, 1*485/232 and WIFI interface. GP-R520 series industrial 4G WiFi router widely used in finance, postal, smart grid, charging piles, self-service equipment, intelligent transportation, environmental monitoring, fire monitoring, security monitoring, water conservancy monitoring, public safety, advertising, industrial control, seismic monitoring, meteorological monitoring, instrument monitoring and other industries.
Features
Industrial Design
- Adopt High-performance industrial-grade 4G module
- Adopt high-performance industrial-grade 32bit MIPS Processor
- Power supply: +7.5V~+32V DC
- Adopt sheet metal cold-rolled steel shell, which has strong heat dissipation
- Protection Level : IP40 (Can be designed up to IP51)
Platform Manage
- Support Online Monitoring
- Support Remote Parameter Backup
- Support Remote Parameter Configuration
- Support Remote Device Upgrades
- Support Remote Reboot and Log Query
Network Feature
- Support Port Traffic Detection
- Support Real-time Link Monitoring
- Support serial port DTU function
- Support MQTT Protocol/Modbus protocol
- Support GPS Positioning (optional function)
- Support Port forwarding, DMZ, and static NAT
Network Function
- Support 4G network and backward compatible with 3G/2G
- Support Dual-Modular/Dual-SIM load balancing, link backup, link aggregation
- Support WiFi IEEE802.11b/g/n protocol
- Support standard RS-232/485 serial port and supports serial port DTU
- Support hardware WDT and provide anti-drop mechanism
- Support multiple VPN protocols
- Support DHCP, DDNS, firewall, NAT, and DMZ host functions
- Support ICMP, TCP, UDP, Telnet, SSH, FTP, HTTP, HTTPS, Modbus and etc Network function
- Support SNMP Management Protocol Support Reboot
Stable & Reliable
- ESD protection for all interfaces to prevent electrostatic shocks
- Multiple device self-test mechanisms ensure smooth links and alarms
- upport network signal strength indicator display in three levels
- Adopt software and hardware watchdog and multi-level link detection mechanism
- Support automatic fault detection and automatic recovery to ensure the stable and reliable operation of the equipment.
